GEAR DIAMETER MAX 600 MM MODULE RANGE 0.5 TO 15 MM BETWEEN CENTER DISTANCE 850 MM MAXIMUM LEAD INSPECTION AT 0° 160 MM MAX. HELIX ANGLE 450 WORK LOAD MAX 200 Kg.
Country Of Make United Kingdom Max Job Dia 250 mm Maximum Work Length 150 mm Maximum Number Of Teeth 159 Pitch Maximum 6 Module Max Cutter Speed 3000 RPM Min Cutter Speeds 1900 RPM With Spare Cams
Gear diameter range: 64–320 mm Module range: 1–12 Maximum width of the shaving cutter: 40 mm Number of teeth: 13–240 Pitch circle diameter range: 73–320 mm Workpiece slide speed: 15/20/30/40 teeth per minute Grinding spindle speed: 690 RPM Grinding slide diameter: 762 mm Pressure angle rotation range: 5–21 degrees Helix angle rotation range: ±35 degrees Vertical adjustment of the grinding…
Maximum. Wheel Diameter: 20 300 mm Number of Teeth: 7 -110l Maximum. Module: 8 Minimum. Module: 1 Stroke of Milling Machine: 6 10 17 mm Milling Tool Taper: DIN 2070 Nr. 40 Quill Adjustment: Axial (11/100) mm Turning Speeds: 25 , 2800 Total Power Requirement: 5 kw
Technical specification: Grinding diameter: 250 mm Grinding length: 350 mm Max. module: 22 Min. module: 1,5 Max. work-piece diameter: 250 mm Grinding travel: 475 mm Max. grinding wheel diameter: 250 mm Min. grinding wheel diameter: 150 mm Grinding wheel speed: 1500-2700 rpm Max. lead angle: 45° Min. flute lead: 125 mm Number of flutes: 3-45 Max. depth of flute: 50…
Max diameter of piece: 400 mm Max module: 8 Max travel of mill-holder slide: 310 mm Min no of cutting gears: 6 Diameter of piece-holder table: 400 mm Bore diameter of table: 80 mm Diameter of piece-holder spindle: 36 mm Max dimension of milling cutter: -Diameter: 160 mm -Length: 160 mm Diameter of spindle mill-holder: -With normal accessory: 32, 40…
Make UMCI Orign UK Vertical Gear hobber Dia 100 mm Width 100 mm Hydraulic Clamping Features Ideal for Automotive Industry and gear cutting of Gear pumps,etc.
